Application

  • Pull out tray , Cash box
  • Pencil drawers , Shallow desk drawers.
  • Economy class drawers
  • Computer keyboard drawers.


Specifications

  • Profile : Side space - 9.5mm(0.37") ; Height - 35mm(1.38")
  • Extension : 3/4 extension slide
  • Load rating: 50 LBS (23kgs)
  • Size : 300mm - 700mm
  • Finish : Clear Zinc-plated(ZP), Black Zinc-plated(BZP), Black Electric Dipping (BED), Yellow Zinc-plated(YZP)
  • Material: Work hardened cold rolled steel

Features

  • Low profile , Simple installation.
  • With trigger release disconnect for easy drawer removal.
  • Non-handed, silent movement.

OEM/ODM drawer slide

Except for standard models, any special custom-design or modification are much welcome, our vision is to use our core competency to provide customers with engineeringsolutions for their various demand in a timely manner during the increasingly competitive market.
