PRODUCT CATALOG

Drawer slide products

Heavy duty drawer slide

Load ratings: 500lbs(227kgs/pair)~120lbs(54kgs/pair).

Series:

  • 76x19mm series (300~500lbs)
  • 58x19mm series (200lbs)
  • 57x19mm, 57x18mm series (200lbs)
  • 56x17.5mm series (160lbs)
  • 53x19mm series (150lbs)
  • 92x12.7mm series (150lbs)
  • 50x12.7mm series (120lbs)

Read More

Medium duty drawer slide

Load ratings: 120lbs(54kgs/pair)~100lbs(45kgs/pair).

Series:

  • 47x12.7mm series (120lbs)
  • 45.6x12.7mm series (100lbs)

Read More

Light duty drawer slide

Load ratings: 80lbs(36kgs/pair)~22lbs(10kgs/pair).

Series:

  • 33x18mm series (80lbs)
  • 36x12.7mm series (50lbs)
  • 35x12.7mm series (50lbs)
  • 35x9.8mm series (50lbs)
  • 27x10mm series (33lbs)
  • 17x10mm series (22lbs)

Read More

Pocket door slide

Load ratings: 33lbs(15kgs/pair).

Series:

  • Pocket door slide (33lbs)

Read More

Flipper door slide

Load ratings: 33lbs(15kgs/pair).

Series:

  • Flipper door slide (33lbs)

Read More

Specialty drawer slide

Load ratings: 50lbs(23kgs/pair)~25lbs(12kgs/pair).

Series:

  • Keyboard slide
    • 35x9.8mm series (50lbs)
    • 27x10mm series (33lbs)
  • Under drawer slide
    • 35x9.8mm series (25lbs)

Read More

Function list:

  • Interlock system.
  • Lock in device.
  • Lock out device.
  • Spring self-closing device.
  • Hold-out
  • Plastic self-closing device.
  • Push open action.
  • Soft-closing cylinder.
  • Soft-down cylinder.

Read More

  • Material: workhardened cold rolled steel, Galvanized steel and Stainless steel are depending on quantity.
  • Finish:
    • Zinc plated with clear chromate(ZP)
    • Black chromate(BZP)
    • Yellow chromate(YZP)
    • Electro-dipping with White or Black (W.ED/B.ED)
  • Travel: 3/4 extension, full extension , overtravel 1"~2" , two way travel.
  • Load ratings: from 22lbs(10kgs) to 500lbs(227kgs) based on testing 18" length.
  • Standard & Approval: ISO9001 & ANSI/BIFMA, FIRA, SGS, DIN.
